Speaker Type: Active 12” subwoofer
Acoustical data
Frequency Response [-10dB]46 – 123 Hz
Max SPL (1 m)129 dB
Directivityomnidirectional
LF12”
LF Voice Coil2.5″
Amplifier
Amp TechnologySMSP digital amplifier
Amp ClassClass D
RMS Power600 W
Peak Power1200 W
Processor
ControllerDSP 28/56 Bit
LimiterPeak, Thermal, RMS
Controls1x Subwoofer attenuation Control
1x Flat/Boosted switch
1x Switch output mode
1x Polarity switch
Input
Signal Input2x XLR (balanced)
Signal Output2x XLR (balanced)
Mechanics
HousingBlack painted Plywood
Handles1 on top
Pole MountM20
Width360 mm (14.72 in)
Height550 mm (21.65 in)
Depth525 mm (20.67 in)
Weight19.8 Kg (43.65 lbs)
